THIS ITEM HAS BEEN DISCONTINUED.
CALL 1-888-747-8593 FOR NEXT SUITABLE ALTERNATE SAW
TX-4 TILESAW W/FLOOD SYS 120V/60Hz Part# 171231
Comes with 10" blade, water pump, rip guide.
The TX-4™ features an innovative maintenance free guide bar system that eliminates the need for regular lubrication. The tilting head allows 22.5 and 45 degree miter cuts. The water distribution system provides a controllable, even flow to both sides of the blade.
One-year limited warranty.
Part# 171231
![]()
TX-4 | 171231 |
Voltage | 120V |
Horse Power | 1-3/4 hp |
Amps | 15 |
Motor RPM | 3,500 |
Blade Capacity | 10" (254mm) |
Arbor Size | 1" (25mm) |
Depth of Cut | 3-1/2" (89mm) |
Depth of Cut at 45° | 2-3/8" (60mm) |
Length of Cut | 24" (610mm) |
Diagonally Cuts | 18" Tile (457mm) |
Weight | 85 lbs. (39kg) |
LxWxH | 44" x 25" x 20" |
LxWxH (mm) | 1118 x 635 x 508 |
Shipping Method | UPS / Fed-Ex |
Built-in fully adjustable miter system for precise 90, 45 and 22.5 degree cuts
![]()
Large aluminum cutting tray with non-slip rubber surface. Guide rail and bearings are shielded from dust and liquids
![]()
Detachable rear tray for water containment
![]()
Large, aluminum cutting table with non-slip rubber surface. Guide rail and bearing are shielded from dust and liquids
![]()
10" Blade capacity along with water distribution system for even flow to both sides of blade
![]()
Easy access water control valve
![]()
TX-4 shown with optional folding stand part#
166445![]()
![]()
