5801217 CC565MBVXL2 14" Masonry Saw 6.5Hp 23961

Part# 580079 Cat # 03725

CC565MBVXL2 14" Masonry Saw 6.5Hp Briggs & Straton-Vanguard 23961

Diamond Products
MSRP: $4,378.00
$
$3,414.84
Choose your options:
Bulk item transport options
Freight Delivery Options(required):
Product Code: 23961
UPC Code: 603461037224
CC565MBVXL2 Masonry Saw 6.5hp Briggs & Straton-Vanguard
Cat # 23961
Part# 5801217

  • Stay level blade guard
  • Removable cutting head
  • Leg kit standard-folding stand optional
  • Side carrying handles
  • Replaceable conveyor cart rails
  • Includes water pump
  • Vulcanized rubber coated material slide cart
  • Open throat cutting
  • Easy and safe access to depth control lock
  • Open back cutting allows longer material to becut
  • Heavy duty frame design help resist damage tosaw body
  • Reinforced slide rails keep the cart runningsmoothly
  • Simple yet strong design allows easymaintenance
  • Sealed drain hole on the bottom of the trayallows quick clean up
Max Depth of Cut: 5"
Blade Shaft Diameter: 7/8"
Arbor Diameter: 1"
Blade Shaft bearings: Flange block ball bearings
Blade shaft Drive: 2 Belts
Blade Mounting: Right (electric) and Left for (Gas)
Blade Raise/Lower: Counter Balanced, Spring tensioned head pivots on two 7/8" flange block bearings
Blade coolant: Dual Spray tubes, pump fed (electric models), Pump from tray (gas models)
Air Filter: 3 Stage cyclone (gas models)
Fuel Capacity: 1 Gallon (gas models)
High Temp Shut off: included (electric models)


Electric Model shown for reference with optional folding stand Part# 6030042 Cat# 46893
*Blade not include

*Includes 4 Straight Leg kit as shown





CC500MXL2 Dimensions



Warning: Use of this equipment can expose you to chemicals including nickel and crystalline silica which are known to the State of California to cause cancer. For more information go to www.P65Warnings.ca.gov. Repeated and/or substantial inhalation can cause serious or fatal respiratory diseases including silicosis. Employ dust controls and protection per OSHA/NIOSH/MSHA
